PTO Power Washers for the Farming Industry

Header Image

  •

    Option 1 - 30 Litre Per Minute Basic PTO (Optional Hose Reel)

    Header Image
    Pump manufacturer
    UDOR
    Working Pressure
    3000 PSI
    Water Volume
    30 L/P/Min
    Bypass Valve
    Trapped-pressure system
    Pump Crankshaft Speed
    1000 RPM
    Gearbox
    No Gearbox required
    Pump Protection
    By-Pass Back to Source
    Heavy Duty
    Double Suction Hose
    Optional
    Hose Reel with 60ft Twin wire H.P. Hose
    Heavy Duty
    pistol and 1-piece steel lance
    Drive
    Telescopic PTO Shaft
    Heavy Duty
    Galvanized steel frame
  •

    Option 2 - The Heavy Duty PTO H.P Hose Reel and 120 ft HP Hose

    Header Image
    Pump manufacturer
    Annovi-Reverberi
    Working Pressure
    3000 PSI
    Water Volume
    21 L/P/Min
    Bypass Valve
    Zero-pressure system
    Pump Crankshaft Speed
    540 RPM
    Gearbox
    No Gearbox required
    Pump Protection
    Burst Disc System
    Heavy Duty
    Yellow water inlet hose
    Water Filter 1
    Damage-proof 80 mic filter
    Water Filter 2
    Pump brass y-strainer filter
    Heavy Duty
    120ft Twin wire H.P. Hose
    Heavy Duty
    pistol and 1-piece steel lance
    Water Bypass
    Return to water tank
    Drive
    Telescopic PTO Shaft
    Heavy Duty
    powder coated steel frame
    Choice of
    CAT 1 or 2, 3-point linkage pins
    Heavy Duty
    6mm Steel bed plate for pump
    Heavy Duty
    50mm Steel square tube legs
    Heavy Duty
    100mm Steel feet plates
    Heavy Duty
    80mm Steel goalpost frame
    Anti-drop
    lance storage facility
    Available
    in choice of any colour
    Also Available
    galvanized

    THIS MACHINE IS ALSO AVAILABLE WITH A 30 LITRE PER MINUTE PUMP.  THIS ONLY RUNS ON TRACTORS WITH A 1000 BOX.

    • Sub Image
    • Sub Image2
    • Sub Image3
  •

    Option 3 - BASIC A Frame Tractor Driven PTO

    Header Image
    Pump manufacturer
    Annovi Reverberi
    Working Pressure
    3000 PSI
    Water Volume
    21 L/P/Min
    Bypass Valve
    Trapped Pressure System
    Pump Speed
    540 RPM
    No Gearbox
    Direct Drive
    Light Duty
    3-Pt linkage galvanised or Powdercoated Frame
    Light Duty
    Water Inlet Hose
    Light Duty
    Plastic Water Filter
    Light Duty
    45ft H.P hose, pistol & lance
    Drive
    Telescopic PTO Shaft
    • Sub Image
  •

    Option 4 - 3-point Linkage A-Frame with H.P Hose Reel PTO Power Washer

    Header Image
    Pump manufacturer
    Annovi Reverberi
    Working Pressure
    3000 PSI
    Water Volume
    21 L/P/Min
    Bypass Valve
    Trapped Pressure System
    Pump Speed
    540 RPM
    No Gearbox
    Direct Drive
    Low Cost
    3-Point linkage galvanised A-Frame
    Low Cost
    Water Inlet Hose
    Low Cost
    Plastic Water Filter
    Low Cost
    120ft Manual Hose Reel and hose
    Low Cost
    Pistol and lance
    Drive
    Telescopic PTO Shaft
    • Sub Image
  •

    Option 5 - HEAVY DUTY Professional Long Life PTO

    Header Image
    Pump manufacturer
    Annovi-Reverberi
    Working Pressure
    3000 PSI
    Water Volume
    30 L/P/Min
    Bypass Valve
    Zero-pressure system
    Pump Crankshaft Speed
    1000 RPM
    Gearbox
    No Gearbox required
    Pump Protection
    Burst Disc System
    Heavy Duty
    Yellow water inlet hose
    Water Filter 1
    Damage-proof 80 mic filter
    Water Filter 2
    Pump brass y-strainer filter
    Heavy Duty
    120ft Twin wire H.P. Hose
    Heavy Duty
    pistol and 1-piece steel lance
    Water Bypass
    Return to water tank
    Drive
    Telescopic PTO Shaft
    Heavy Duty
    powder coated steel frame
    Choice of
    CAT 1 or 2, 3-point linkage pins
    Heavy Duty
    6mm Steel bed plate for pump
    Heavy Duty
    50mm Steel square tube legs
    Heavy Duty
    100mm Steel feet plates
    Heavy Duty
    80mm Steel goalpost frame
    Anti-drop
    lance storage facility
    Available
    in choice of any colour
    Also Available
    galvanized
    • Sub Image
    • Sub Image2
  •

    Option 6 - PTO and Drain Cleaning Combi Unit

    Header Image
    Pump manufacturer
    Annovi-Reverberi
    Working Pressure
    3000 PSI
    Water Volume
    30 L/P/Min
    Bypass Valve
    Zero-pressure system
    Pump Crankshaft Speed
    1000 RPM
    Jetting Unit
    30 Litres per minute @ 3000 PSI
    Pump Protection
    Burst Disc System
    Heavy Duty
    Yellow water inlet hose
    Water Filter 1
    Damage-proof 80 mic filter
    Water Filter 2
    Pump brass y-strainer filter
    Heavy Duty
    120ft Twin wire H.P. Hose
    Heavy Duty
    80 metres Jetting Hose
    Water Bypass
    Return to water tank
    Drive
    Telescopic PTO Shaft
    Heavy Duty
    powder coated steel frame
    Choice of
    CAT 1 or 2, 3-point linkage pins
    Anti-drop
    lance storage facility
    Available
    in choice of any colour
    • Sub Image
  •

    Option 7 - Twin Gun, Two-Man Operational Systems

    PUMP MANUFACTURER
    We use Interpump, CAT, Hawk, Annovi Reverberi and Pratissoli Pumps depending on customers specifications.  We select the best available model depending on the customers type of cleaning requirements  i.e. cleaning speed & times, water volume, various pressures, pump crankshaft speeds and gearbox driven options etc.

    WORKING PRESSURES
    We can supply working pressures of 2000, 2500, 3000, 4000, 5000 & 5800 psi.

    WATER VOLUMES
    We can supply water volumes from 15, 21, 23, 25, 30, 41, 50, 80 & 100 litres per minute.

    BYPASS VALVES
    We can supply machines with Zero-Pressure or Trapped-Pressure Bypass

    GEARBOXES
    We can supply gearbox drive machines for 540 PTO box speed tractors only.

    PUMP PROTECTION
    Either burst disc or safety valve system.

    INLET & BYPASS HOSES
    Long life, yellow water inlet and braided bypass return hose.

    INLET TWIN WATER FILTER SYSTEM
    Filter 1: Element damage-proof 80 micron filter
    Filter 2: Pump brass y-strainer filter

    HIGH PRESSURE HOSE
    Both gun hoses must be heavy duty and we can supply any lengths up to 250ft.  Common lengths are 120ft, 150 and 250ft

    PISTOLS & LANCES
    Selected heavy duty pistols and 1 metre, one-piece, stainless steel lances for long life and health & safety reasons.  Longer lances can be supplied for high level cleaning including telescopic lances.  For extra power we can supply turbo nozzles which can boost your working pressure by a further 1500 psi.

    HEAVY DUTY FRAMES
    Frames have to be made according to the customers specifications i.e with or without water tank, what size and direction of high pressure hose reels, single or twin pump, choice of various powder coated colours or galvanised, anti drop lance storage facilities, choice of category 1 or 2, 3-Point linkage pins.

    • Sub Image
    • Sub Image2
  •

    Option 8 - Commando 6000 Servies

    Header Image

    The Aquawash Commando 6000 series with a large 1,500 gallon capacity, provides the contractor, pig or poultry farmer a self-contained, high performance PTO pressure cleaner.
    This versatile unit can also be used for civil engineering projects, open-cast mining & a wide variety of tasks.

    STANDARD FEATURES

    PTO Drive  shaft & guard
    Choice of Triplex Ceramic Plunger Pump
    Proportional Flow Unloader & Pressure Gauge
    90 Metre (300ft) Capacity Manual Hose Reel
    Large capacity inlet filter
    1500 Gallon Capacity Water Tank
    Removable Drawbar Jack
    Low level filing port and coupling.
    Manhole inspection hatch
    Access Ladder
    Brakes
    Road Lights
    Safety Valve
    Quick release gun allows tools to be interchanged
    75 Metre (240ft) Two wire ½" High Pressure Hose
    1.0 metre Single Lance
    Fully adjustable pressure

    OPTIONAL ACCESSORIES

    Recirculating Anti-Freeze System
    Chemical Injector
    Foam Application Equipment
    Sand Blasting Equipment
    Drain Jetting Hoses & Jest
    Insulated Frost Cover
    Hydraulic Hose Reel Rewind
    Inlet Hose Reel


    UNLOADER VALVE
    A proportional unloader valve & pressure gauge controls flow & indicates working pressure

    ACCESS LADDER HATCH & LOW LEVEL FILLING PORT
    Allows easy tank filling & access

    PTO DRIVE SHAFT
    A PTO drive shaft & guard supplied to the correct length, with a choice 540 or 1000 coupling.

    OPTIONAL ANTI-FREEZE SYSTEM
    A fully recirculating anti-freeze system protects the pump and all pipework during winter periods.

    LIGHTS
    Full road lights to EC standards, fully enclosed to protect against damage.

    MANUAL HOSE REEL
    This 300ft capacity reels allows partial or full discharge & recovery of the hose during or after use. Minimising hose damage and maximising labour efficiency.

    LOCKING PIN & GUN HOLDER
    The locking pin controls rotation of the reel.  The quick release coupling safely secures the gun during transport.

    PLUNGER PUMP
    A choice of Triplex ceramic plunger pumps with brass cylinder head & stainless valves provides long term reliability.

    FLEXIBLE DRIVE COUPLING
    The flexible drive coupling, fully guarded, absorbs excessive load protecting the pump.

    • Sub Image
  •

    Option 9 - Aquawash Field Drain Cleaner

    Header Image

    Aquawash also specializes in equipment for cleaning field drains because of the lengths of drains to be cleaned.  Aquawash' range of PTO machines can only pull the drain hose between 10 to 23 metres (30 to 70ft) up the drain depending on drain diameter.  We can achieve a slightly longer push up the drain by using a pulse jet, but not the lengths the proper field drain machine can achieve.  Aquawash Supply equipment which has a rigid HPE hose which is pushed into the drain up to a length of 500 metres (1500ft).

    Junior

    Hydraulic system; 2 hydraulic motors, 1 valve back, 1 pressure compensated valve, 1 flow regulator. Hose guiding, manual adjustable. Hose withdrawal, hydraulic.

    Delta

    Hydraulic system; 2 hydraulic motors, 1 valve back, 1 pressure compensated valve, 1 flow regulator. Hose guiding, hydraulic adjustable. Hose withdrawal, hydraulic.

    Senior

    Hydraulic system; 3 hydraulic motors, 4 cyclinders 1 valve block, 1 pressure compensated valve, 1 flow regulator. Hose guiding, hydraulic adjustable. Hose withdrawal, hydraulic.

    Features on all types

    5-chamber piston diaphragm pump, max. output 115 ltr./min - 50 bar. Working speed 70 - 80 ltr./min - 35 bar, 300 metre standard length cleaning hose, 10 metre suction hose with filter & float, 10 meter return-flow hose, distance counter, Required tractor hydraulics; single-acting system with free return line or double acting system.
